Cole-Parmer 单流输入泵控制器，24 VDC

Cole-Parmer 单流输入泵控制器，24 VDC

配合使用批次或流量控制器精确控制泵

PFA传感器符合美国药典VI级

这些液体涡轮流量传感器是长期耐腐蚀，在苛刻的情况下，性能无故障。传感器被放置在转子叶片的边缘附近，为所有颜色液体以提供准确的流量测量。通过传感器连接的红外光束，流进管里，并转换为5到30 V方波脉冲输出。一米的PVC??电线包含RVC插孔输入到批处理或流量控制器（以下单独出售）。如果使用记录仪，面板仪表，或PLC，只需取出千斤顶，露出两线电缆安装电压输出。安装这些涡轮流量传感器到任何位置，他们不需要直流或其他专业安装。PFA和PVDF一次性可替换的传感器应用也可以设置为永久流量传感器。PFA和PVDF传感器标准配备装配夹。标准安装夹;聚丙烯管座我们也可以提供(联系我们的应用程序专家)传感器与软管倒钩或螺纹管件一起供应。

316L不锈钢（SS）涡轮传感器符合化工，医药，半导体，环保产业的高压需求。耐腐蚀性强。

Use in conjunction with batch or flow controller for precise pump control

PFA sensors meet requirements of US Pharmacopeia Class VI

These liquid turbine flow sensors are corrosion resistant for long-term, trouble-free performance in demanding situations. Sensor is positioned in close proximity to the edges of the rotor blades to provide accurate flow measurements for all colored liquids. Flow in your tubing is picked up via the IR beam in the sensor connection, and converted into a 5 to 30 V square wave pulse output. One meter of PVC cable is included with an RVC jack for input into the batch or flow controllers (sold separately below). If using a recorder, panel meter, or PLC, simply remove the jack to expose the two-wire cable for installation of voltage output.

Mount these turbine flow sensors in any position; they do not require a flow straightener or other specialized installation. The PFA and PVDF sensors are replaceable for single-use applications or can be set up as permanent flow sensors. PFA and PVDF sensors come standard with a mounting clip; polypropylene tube holders are also available (contact our Application Specialists). Sensors are available with hose barb or threaded fittings.316L Stainless Steel (SS) Turbine Sensors are rated for high-pressure requirements in chemical, pharmaceutical, semiconductor, and environmental industries. Highly corrosion resistant.
